| model | MC-A37 |
| Main control chip | SSC373 |
| Image Sensor | SC2337P 3 megapixels, 1/3″ CMOS |
| Video Processing | H.265+/H.265/H.264 video encoding, support bitrate 0.1M~3Mbps adjustable; support frame rate 1~25fps adjustable; |
| Image Output | Main stream: 25FPS@(2304×1296, 1920×1080, 1280×720); |
| Sub-stream: D1, VGA, 640×360; | |
| Audio Interface | Audio linear 1-way input 1-way output; |
| Audio Processing | G.711 coding standard, supports two-way voice intercom, and supports audio and video synchronization; |
| IRCUT Interface | Integrated IRCUT switching circuit, automatic/external control/manual/timing to control IRCUT day and night mode |
| Network Interface | 1 RJ45 Ethernet port, 10/100M adaptive; |
| Light board interface | PWM infrared, PWM warm light; |
| reliability | The power supply and network are fully lightning-proof, in compliance with national standard GB/T17626.5 and international standard IEC61000-4-5; |
| Business Functions | Support OSD, real-time audio and video transmission, accurate human detection, dual light source alarm, and sound alarm; |
| Network Protocol | Support HTTP/RTSP/DHCP/NTP/ONVIF and other network protocols |
| power supply | DC12V power input interface power consumption 90mA |
| Work Environment | -40~+65℃ |
| size | 38(length) * 38(width) |
A37 3MP Duallight IP Camera Module
Features:
“1,M-star SSC373+SC2337P 1 /3 inch 3mp CMOS sensor ”
“2 ,supportH.265+,H.265,H.264 encoding”
“3, Support soft photosensitivity: dual light mode, full color mode, infrared mode;”
“4, Support intelligent analysis: accurate human detection, custom area;”
“5, support voice intercom, voice broadcast, and custom voice;”
“6 , support image flip, support digital wide dynamic;7 ,support Onvif;”
“8 ,supply SDK（WINDOWS,Android,LLinux) Development Kit”
