Guard viewer XVR301-16G3 5MP-N 16CH BNC+8CH IPC Hybrid DVR 1U

Home  /  No Categories

Key Features

*Support VCA Detection by Camera: Intrusion Detection, Cross Line Detection, Enter Area, Leave Area,

Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking,

Ultra Motion Detection (UMD), just compatible with uniview camera or third party camera had compatible with uniview private protocol

* Compatible with third-party IPCs for fully automatic addition, modification of third-party IP addresses, OSD, image parameters, etc.

*Live view 32ch*4k ip camera;

* Synchronous playback:2 x 4K@30, 3 x 5MP@30,  4 x 4MP@30, 5 x 3MP@30, 8 x 1080p@30, 16 x 720p@30,32 x D1

*Incoming/Outgoing bandwidth:160/64Mbps

*Support Mobile APP: Guard Viewer (iOS, Android); Client PC software: Guard Station; IP Search tool: Guard tool

*Support ODM, OEM, Such as Manufacturer Name, Model Number, Web/Boot Logo customization

*Support 32-channel input,2lan network port, Support 1*mic and1* speaker connection on nvr;

*Support Ultra265/H.265/H.264 video formats

*Support mainstream cameras of ONVIF conformance (Profile S, Profile G, Profile T) and RTSP protocols

*HDMI and VGA simultaneous output

* Supports intelligent search, playback and backup functions, effectively improving the efficiency of video retrieval and playback.

*2 SATA HDDs, up to 8TB for each HDD

* support UPnP、NTP、SMTP、FTP、PPPoE、DDNS、DHCP

*Support remote maintenance across public network

Contact Us
Category:

Product specifications

Model XVR301-16G3
Video/Audio Input
Analog Video Input 16-ch, BNC
IP Video Input 8-ch(only IP up to 24ch), each channel up to 8MP
Supported Analog Camera Types Support AHD input:

5MP@12fps

4MP@15fps

1080P@30fps

720P@30fps

Support TVI input:

5MP@12fps

4MP@15fps

1080P@30fps

720P@30fps

Support CVI input:

4MP@15fps

1080P@30fps

720P@30fps

Support CVBS input

Audio Input 1-ch, RCA
Two-way Audio 1-ch, RCA
Network
Incoming Bandwidth 40Mbps
Outgoing Bandwidth 64Mbps
Remote Users 128
Protocols TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE
Video/Audio Output
VGA Output 1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz
HDMI Output 1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz
Audio Output 1-ch, RCA
Synchronous Playback 16-ch
Encoding
Recording Resolution 5MP Lite/4MP Lite/1080P/720P/4CIF/CIF
Recording Frame Rate Main stream:

5MP Lite@6fps

4MP Lite@8fps

2MP Lite@15fps

2MP@8fps

720P@15fps

Sub stream:

D1@15fps(Max)

Hard Disk
SATA 1SATA interface
Capacity Up to 6TB for each HDD
External Interface
Network Interface 1RJ45 10M/100M self-adaptive Ethernet Interface
USB Interface Rear panel:2 x USB2.0
General
Power Supply 12V DC

Power Consumption: ≤ 8 W( without HDD )

Working Environment -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing)
Dimensions(W×D×H)
Weight ( without HDD ) ≤1.1 Kg ( 2.42lb )
