| Model : | MC-H12S | ||
| Main control chip: | SSC359 ARM Cortex0A53 1.2GHz External 4G DDR | ||
| Image sensor : | IMX577 12 megapixel, 1/2.3″ CMOS ; | ||
| Video processing: | H.265+/H.265/H.264 video encoding, support bit rate | ||
| 0.1M~12Mbps adjustable; support frame rate 1~30 frames/ | |||
| /second adjustable; | |||
| Image Output: | Main stream: 25@FPS (4000×3000) 30@FPS (3840×2160, | ||
| 3072×2048, 2592×1944) 60@FPS (2560×1440, 2304 × | |||
| 1296,1920×1080,1280×720) | |||
| Sub-stream: 720×480, D1, VGA, 640×360; | |||
| Audio interface: | audio linear 1-way input 1-way output | ||
| Audio processing : | G.711 coding standard, supports two-way voice intercom, | ||
| supports audio and video synchronization; | |||
| IRCUT interface: | ntegrates IRCUT switching circuit, automatic/external | ||
| control/manual/timing to control IRCUT day and night mode | |||
| Network interface: | 1 RJ45 Ethernet interface, 10/100M adaptive; | ||
| Light board interface: |
CDS, PWM infrared, PWM warm light; | ||
| The IO interface | supports electric zoom and auto focus interfaces, which | ||
| require zoom lenses, zoom control panels, and zoom programs. | |||
| Reliable: | power supply and network comprehensive lightning | ||
| protection, in line with national standard | |||
| GB/T17626.5 and international standard IEC61000-4-5; | |||
| Business functions: | support OSD, real-time audio and video transmission, | ||
| perimeter algorithm detection, dual light source alarm, and | |||
| and sound alarm | |||
| network protocols: | supports HTTP/RTSP/DHCP/NTP/ONVIF/P2P and other network | ||
| protocols, and GB28181, RTMP and various NVR docking | |||
| protocols are optional; | |||
| Mobile monitoring | Support mobile monitoring (iOS, Android) APP: VideoLink | ||
| Power supply : | DC12V | ||
| Size : | 2*38(length) * 38(width) | ||
| Working environment: |
-45-80 | ||
MC-H12S 12MP smart AI StarLight Module(SONY IMX577)
Features:
1. Mstar SSC359+Sony IMX577 1/2.3 ” 12 mp CMOS sensor;
2. 2T computing power;
3.Support H.265+, H.265, H.264 encoding,Onvif;
4. Support 2 types of light signal control: CDS, PWM signal;
5. Support soft photosensitivity: full color mode, infrared mode, dual light mode;
6. Support image flip, support HDR;
7. Deep perimeter: support cross-border detection, enter area, leave area, area intrusion 4 kinds of deployment modes
8.Can classify motor vehicles, non-motor vehicles, and pedestrians for detection and deployment;
9. Support voice intercom, voice broadcast, custom voice;
10. Provide SDK (WINDOWS, Android, Linux) development package
