| model | MC800S |
| Main control chip | SSC338 |
| Image Sensor | 8 mp, 1/2.8″ CMOS IMX415 |
| Video Processing | H.265+/H.265/H.264 video encoding, support bitrate 0.1M~12Mpbs adjustable; support frame rate 1~20 frames/second adjustable; |
| Image Output | Main stream: 20@FPS(3840×2160), 30FPS@(3072×2048, 2592×1944, 2560×1440, 2304×1296, 1920×1080, 1280 ×720); |
| Sub-stream: 720×480, D1, VGA, 640×360; | |
| Audio Interface | Audio linear 1-way input 1-way output; |
| Audio Processing | G.711 coding standard, supports two-way voice intercom, and supports audio and video synchronization; |
| IRCUT Interface | Integrated IRCUT switching circuit, automatic/external control/manual/timing to control IRCUT day and night mode |
| Network Interface | 1 RJ45 Ethernet port, 10/100M adaptive; |
| Light board interface | CDS, PWM infrared, PWM warm light; |
| IO Interface | Support electric zoom and auto focus interface, need to be matched with zoom lens, zoom control panel and zoom program |
| reliability | The power supply and network are fully lightning-proof, in compliance with national standard GB/T17626.5 and international standard IEC61000-4-5; |
| Business Functions | Support OSD, real-time audio and video transmission, human detection, dual light source alarm, and sound alarm; |
| Network Protocol | Supports network protocols such as HTTP/RTSP/DHCP/NTP/ONVIF/P2P, optional GB28181, RTMP and various NVR docking protocols; |
| Mobile phone monitoring | Support mobile monitoring (iOS, Android) Danale; |
| power supply | DC12V power input interface 170mA |
| Work Environment | -40~+85℃ |
| size | 2×38(length) * 38(width) |
MC800S 8MP smart AI StarLight Module(SONY IMX415)
Features:
“1,M-star SSC338+Sony IMX415, 1/2.8 inch 8MP Star Light CMOS sensor;”
“2 ,bring1T Computing power, external algorithms can be used;”
“3 ,supportH.265+、H.265. H.264coding;”
“4 ,support2 Types of light signal control:CDS,PWM signal;”
“5, Support soft photosensitivity: full color mode, infrared mode, dual light mode;”
“6 , support image flip, supportHDR;”
“7, Support intelligent analysis: human detection, custom area;”
“8 , support voice intercom, voice broadcast, and custom voice;9 ,supportOnvif;”
“10, support character overlay;”
11.IP address filtering;
“12 ,support POE extension;”
“13 ,supply SDK（WINDOWS,Android,Linux) Development Kit”
