MC-J86 – 8MP Black Light IP Camera Module SigmaStar SSC378DE + SmartSens SC850AI

Home  /  No Categories

1.SSC378DE+SC850AI 8 megapixels, 1/1.8″ CMOS sensor;
2. Support H.265+, H.265, H.264 encoding; Onvif;
3. Support softphotosensitivity: full-color mode;
4. Support intelligent analysis: pedestrian detection, vehicle type detection, area detection, trip wire detection;
5. Support voice intercom, voice broadcast, custom voice;
6. Support image flip, support digital wide dynamic;
7. Provide SDK (WINDOWS, Android, Linux) development package

Contact Us
General
Model MC-J86
Main Control Chip SSC378DE
Image Sensor SC850AI, 8MP, 1/1.8″ CMOS (blacklight)
Video
Video Encoding H.265+ / H.265 / H.264
Bitrate 0.1 – 4 Mbps (adjustable)
Frame Rate Resolution-dependent; see Main Stream below.
Main Stream 20FPS @ 3840×2160; 25FPS @ 3072×2048; 30FPS @ 2592×1944, 2560×1440, 2304×1296, 1920×1080, 1280×720
Sub Stream D1, VGA, 640×360
Lighting
Light Mode Full-color (warm light blacklight)
IRCUT Integrated circuit; auto / manual / timer control
Light Interface PWM infrared + PWM warm light
Audio
Audio Codec G.711
Audio Interface 1-ch linear input + 1-ch linear output
Two-way Audio Supported
Smart Features
Intelligent Analysis Human, vehicle and non-motor vehicle detection; area and tripwire detection
Alarm Sound alarm
Network
Network Interface 1 × RJ45, 10/100M self-adaptive Ethernet
Protocols HTTP, RTSP, DHCP, NTP, ONVIF
Mobile APP VideoLink (iOS & Android)
SDK Windows, Android, Linux
Power & Environment
Power Supply DC 12V
Current Consumption 150 mA
Working Temperature -40°C to +65°C
Lightning Protection GB/T17626.5, IEC61000-4-5
Dimensions 42 mm × 42 mm
Image Processing Image flip; digital wide dynamic range

Wiring Diagram
